# FIXED
Fixed point number package
Dr. Heinrich Hohl <>
Version 1.0.0 - 2016-10-01
## Introduction
This package provides words for convenient handling of fixed point numbers.
A fixed point number (f) is an integer number with an implied decimal point at a specified position. Fixed point numbers may be used instead of floating point numbers if only basic arithmetic operations (+, -, \*, /) are required in an application.
What does *implied decimal point* mean?
Let us assume that your application deals with weight (in kg) and price (in EUR). In this case you would store weights and prices as follows:
- Weight: 1 kg = 1.000 kg = 1000 g = 1000
- Price: 1 EUR = 1.00 EUR = 100 ct = 100
Although weight and price are officially shown in kg and EUR, they are internally stored in grams and cents. Before you input or output a fixed point number, you must specify the position of the implied decimal point. In the above example these positions are 3 and 2 digits from the right, respectively.
## Versions
The package is available in versions for the following FORTH systems:
|System |Standard |Type |Files |
|------------------------|---------|------|---------------------------------|
|PC/FORTH (LMI) |Forth-83 |16-bit|[fixed\_lmi.txt](fixed_lmi.txt) |
|SwiftForth (Forth, Inc.)|ANS Forth|32-bit|[fixed\_sf.f](fixed_sf.f) |
|VFX Forth (MPE) |ANS Forth|32-bit|[fixed\_vfx.fth](fixed_vfx.fth) |
The package was developed under LMI PC/FORTH in 1992 and published in the German Forth magazine [Vierte Dimension Nr. 2/1992, p.7][1]. The LMI version is included for completeness and because someone might still want to use the package on a 16-bit system.
It is also instructive to see how much simpler the code became after rewriting the package for 32-bit systems. The following description will concentrate on the 32-bit versions (SwiftForth, VFX Forth) of the package.
## Installation
Use the following commands to install the package:
- SwiftForth: `INCLUDE fixed_sf.f`
- VFX Forth: `INCLUDE fixed_vfx.fth`
This makes the fixed point words available. After loading you still have a standard system. The number conversion routine of the Forth system is not modified by this package.
## Glossary
The package adds the following words to the system:
PLACES FIXED (F.) F. F.R
See [**glossary.md**](glossary.md) for stack comments and descriptions of the defined words.
## Usage
Use `PLACES` to specify the number of places behind the decimal point. Input a number (with or without decimal point), immediately followed by `FIXED` which converts the input to a fixed point number. It does this by appending zeros or by truncating excessive digits behind the decimal point as required. The number is now in a well defined format and can be stored, used for calculations, or output.
### Examples
3 PLACES
6 FIXED F. --> 6.000 ok
2.4938 FIXED F. --> 2.493 ok
6 FIXED 2.4938 FIXED + F. --> 8.493 ok
8.493 1 PLACES F. --> 8.4 ok
: .WEIGHT ( f -- ) 3 PLACES F. ;
: .PRICE ( f -- ) 2 PLACES F. ;
### Important rules
1. Do not put any other words between the number input routine and `FIXED`. Depending on the FORTH system, words such as `.S` may alter the contents of `DPL`.
2. On 32-bit systems, fixed point numbers are represented by single length numbers.
3. Use standard words for storage (`@ ! CONSTANT VALUE VARIABLE`) and for stack manipulation (`DUP DROP SWAP OVER ROT` etc.)
4. Use `+` and `-` to add and subtract two fixed point numbers, respectively. Both operands must be based on the same number of places, and the result will inherit this number of places.
5. Use `*` and `/` to multiply or divide two fixed point numbers. The operands and the result are generally based on different numbers of places. Afterward, you must scale the result by a suitable power of ten.
## Conformance
This package largely conforms to Forth-83 (LMI) and ANS Forth (SwiftForth, VFX). Nonstandard words that should be mentioned:
- `DPL` contains the decimal point location after an integer number conversion has been performed
- `{ ... }` marks block comments in SwiftForth
- `(* ... *)` marks block comments in VFX Forth
- `PACKAGE PRIVATE PUBLIC END-PACKAGE` are used for information hiding in SwiftForth
- `MODULE EXPORT END-MODULE` are used for information hiding in VFX Forth
[1]: https://www.forth-ev.de/filemgmt/viewcat.php?cid=2
